Thermal Insulation Material |
Closed Cell Elastomeric Nitrile Rubber Foam |
|
|
Density |
40 to 60 Kg/m³ |
ASTM D 1667 |
|
Service Temperature |
-57°C to 125° C |
Becomes hard at -57° C but can be used at -200° C |
|
Thermal Conductivity |
0.0330 W/m°K at 0°C
0.0356 W/m°K at 24°C
0.0366 W/m°K at 32°C |
ASTM C 518 |
FIRE & SMOKE CHARACTERISTICS a)Flammability
b)Flame Spread & Smoke Density Test
c)Smoke and Toxicity Test
d)Self Extinguishing |
Class V-0
Class A
Passed
Passed |
UL 94-1997
ASTM-E84
IMO Res. MSC 61(67) Anx 1.P2
ASTM D 635 -06 |
|
Water absorption (%) |
<5% (by weight) |
ASTM D 1056 |
|
Water Vapour Permeability - perm.in |
<0.1 perm.in |
ASTM E 96 |
|
Mold Resistance Fungi Resistance |
Meets Requirement (Rating 1) No Growth |
UL 181 ASTM C 1338 |
|
Ozone Depleting substances (CFC/HCFC) |
Not Detected |
USEPA 5021A / USEPA 8260C |
|
Ozone Resistance UV Weather Resistance |
No Cracks Excellent |
ASTM D 1149
ASTM G154 |
|
Flexibility |
Excellent ( Not rupture) |
ASTM D 1149 ASTM G154 |
|
N - Nitrosamines Release |
Not Detected |
FDA CPG 7117.11 |
|
Corrosion on copper, stainless steel |
Non Corrosive |
DIN 1988 |
|
ROHS |
Not Detected |
EN Restriction of the use of hazardous substances directive (ROHS) 2002/95/EC |
